This fully automatic single-piece wet wipe rolling machine comes with advanced features such as a top and bottom cutting blade structure, a standard double-blade fabric cutting system, and a 3-inch airshaft for secure film mounting. It automatically splices the film and seals it using a tape bonding method, ensuring smooth and efficient operation.
With both automatic and manual modes, it offers flexibility to meet diverse production needs. The film unwinding rack can accommodate rolls with a maximum diameter of 350mm and a width of up to 150mm, making it compatible with various packaging materials.
| Production speed | 100-200 wipes/min | Rolled wipe diameter | 20-40mm |
| Quantity per pack | 1 wipe/pack | Fold type | V-fold (cross fold before rewind) |
| Wipe material | Spunlace fabric, dust free paper | Wrapping film | PE/PET, OPP/PE (aluminum metallized film) |
| Material weight | 45-65 g/m² | Package size | Length: 160mm Width: 30-50mm (need to change forming device) |
| Voltage | 380V 50HZ | Wetting system | Tank with agitator |
| Total power | 12kW | Liquid tank capacity | 400L |
| Parent roll width | 200-300mm | Machine dimensions (L×W×H) | 7830×1400×1670mm |
| Open wipe length | 200-300mm | Liquid tank size | 900×900×1900mm |
| Open wipe width | 200-300mm | Machine weight | 2800kg |
| Rolled wipe length | 70-100mm |
