Dachang is a professional paper machinery manufacturer, and produces machines such as the DC 2070A multi-piece wet wipe machine. This particular machine is an automatic wet wipe folding and packing machine and features a fully automatic control system. The production speed can reach up to 1,000 pieces/minute, making it suitable for wet tissue and cosmetic companies to meet the increasing supply demand.
This automatic wet wipe machine is easy and flexible to sue. It allows users to freely adjust the length and width to make wet wipes in different sizes, including miniature packages, in order to meet the needs of more customers and gain an increase in marketing and sales.
Parameters of DC-2070A Wet Wipe Machine| Power | three phase 380V , 50Hz |
| power | about 30KW |
| Machine size(L× W× H) | 8000×1520×2350 |
| Unfolded size(mm) ( L× W) | (150-200 )× (160-200 ) |
| Folded size(mm) ( L× W) | (75-100 )× (65-75 ) |
| Pieces/pack | 5-30 pcs |
| Designed speed | 1200 pcs/min |
| Production speed | 1000 pcs/min or 50 packs/min |
| Waste rate | ≤2% |
| Moistening | ±6% |
| Labeling size | ±2mm |
| Punching size | ±2mm |
| Folding manner | Z, W,C |
Note: the folding style (L, W) and pieces/pack can be adjusted.
Raw Material Specification
1. Packing film: Width ≤ 280, Diameter ≤400
2. Spunlace: 320 ≤ Width ≤ 400, Diameter ≤1200
3. Label: Width ≤ 60, Diameter ≤300
Features and Benefits
1. Mitsubishi electrical components: high quality, stable performance, longer service life.
2. Spunlace longitudinal folding device: you can adjust the folding size and style for different consumer groups
3. Immersing-type spunlace moistening device: even and complete moistening.
4. Servo systems for the entire wet wipes production line include a folding servo, packaging servo, film feeding servo, labeling servo, and window opening servo, which makes it easy and flexible to control the machine, and the machine will be more stable and reliable.
5. Auto/manual control: to meet control needs in different production processes.
6. Four emergency stop buttons distributed along the long edge of the machine: pressing emergency stop button will stop the mechanical part of the wet wipe machine immediately to ensure that the production process is controllable.
7. No stop in power phase change using electric differential gear to ensure operational stability.
8. Double labeling machines, automatic inline code marking, all in one operation from production to packaging.
Working Steps of the Wet Wipe Machine
Material unwinding → slitting → longitudinal fold → synchronous spunlace feed → cut fold → stacking count → synchronous conveying → automatic packaging → inline marking → automatic window opening → automatic labeling → hot seal cutting → air extrusion → delivery
Main Configuration of the Wet Wipe Machine
1) Spunlace cutting device;
2) Spunlace longitudinal folding device:
3) Wet wipe cutting device: high-speed steel blade which can be replaced individually; bottom knives are manufactured with tungsten steel that never rust, to ensure long service life;
4) Spunlace crosswise folding device;
5) Automatic counting and stacking device: the number of pieces to be counted out can be set via the touch screen, and the stacking is driven by servo motor;
6) Packaging film window opening unit;
7) Double labeling devices;
8) Packaging film forming device;
9) Packaging films longitudinal sealing device, cylinder opening sealing device.
